Make
Your Own Automotive Diagnostic Equipment book on PDF
Learn to make your own
automotive repair diagnostic equipment and gadgets that save you lots of time
and money. Written in a simplified way, only a strong basic knowledge of
electronics is needed. If not, you can also get our electronic course books 1
& 2. We have all your need to succeed in making your own equipment and fix
your car. This book on PDF is also at a 30% off price from the printed format.
(Click link
bellow for secure purchase. After purchase your download link will be sent to
you… Enjoy.)
Make Your Own Diagnostic Equipment (MYODE)
(Includes circuit
explanations, parts list and detailed explanation on how to build)
By Mandy Concepcion
This book, “Make
Your Own Diagnostic Equipment” came about from the need of many readers and
viewers to be able to make and maintain fairly simple diagnostic gadgets. It is
meant to show and guide the professional technician and DIY mechanic on how to
make these gadgets. In many cases, due to the nature of the equipment industry,
it is very expensive or virtually impossible to get these tools. The reason
being is that often times tool makers don’t see a profit in making these simple
but effective gadgets. Most, if not all of these tools, are invaluable in
diagnosing modern automotive systems. You can estimate that having one of these
tools, at the right time when needed, will cut your diagnostic time by at least
50%. Of course, knowing how to use it is also important. However, by definition
if you’ve already studied how the gadget works, how to build it an also ended
up building it yourself, you’ve already passed the learning curve and chances
are you’ll know how to use it. At the very least, reading this book will put
you in a much better position to also asses diagnostic issues and on the use of
other important tools of automotive diagnostics.
It is our hope with
this work to enlighten the professional and DIY mechanic on the use,
construction and operation of modern automotive diagnostic gadgets. Use this
information to the beast of your abilities and be on the diagnostic driver seat.
Table of
Contents
* Automotive Low
Pressure Transducer
* Building the Low
Pressure Transducer
* Using the Low
Pressure Transducer
* Polarity LED Test
Light
* Using the
Polarity LED Test Light
* Stress Loaded
Test Light
* Using the Stress
Loaded Test Light
* Building the
Stress Loaded Test Light
* Fuel-Pump Relay
& the Stress Loaded Test Light
* Dual Polarity
& 5 Volt Reference Test Light
* Amplified Sensor
Tester
* Injector &
Coil Magnetic Detector
* Fuel Injector
Pulser
* ECM-ECU Memory
Saver Tool
* Loaded Injector
Noid Light
* Using the Loaded Injector
Noid Light
* 5 Volt Reference
Simulator
* Parasitic Draw
Amp Meter
* Using the
Parasitic Draw Amp Meter
* Fuse Voltage Drop
Short Identifier
* How to Use the
Fuse Voltage Drop Short Identifier
* Ignition Primary
DIS - COP Probe
* How to Use the Ignition
Primary DIS Probe
* Drive-By-Wire
Motor Actuator Controller
* How to Use the
Drive-By-Wire Actuator Controller
* Ignition Key
Transponder Detector
* Using the
Ignition Key Transponder Detector
* Magnetic Sensor
Induction Simulator
* Using the Magnetic
Sensor Induction Simulator
* O2 Sensor
Simulator
* Using the O2
Sensor Simulator
* ABS Speed Sensor
Simulator
* Using the ABS
Speed Sensor Simulator
* ABS Speed Sensor
Simulator, Bleeding the Brakes
* Optical CAM and
CRANK Sensor Simulator
* Using the Optical
CAM and CRANK Sensor Simulator
* OBD-2 Data Link
Connector Breakout Box
* Using the OBD-2
DLC Breakout Box
